01

Klingspor product groups

Yellow Klingspor LS 312 J-FLEX abrasive belt on a grey background

02

Selection criteria

Which features determine the result?

Start with the material, its initial condition and the intended result: do you need to remove material, refine a surface or cut a workpiece? Abrasive belts and hook-and-loop discs made from coated abrasives differ in grain type, grit, bond, backing and coating density. Paper, cloth and film serve different purposes depending on contours, load and finish. For cutting discs, dimensions and mounting must also match the machine; cutting is a different task from grinding or polishing.

03

Klingspor range

Klingspor abrasives in the range

The listing contains Klingspor products in various forms, including abrasive belts, hook-and-loop discs and cutting discs. Check each product for suitability for the material, machine and processing step.

No products found

No products are currently listed in this category. Request a call back and we will help you find the right product.

Request a callback

04

Klingspor selection guide

Choose Klingspor abrasives for the task

Review the abrasive currently in use as well: where do loading, insufficient removal, an uneven scratch pattern or short service life occur? A useful comparison requires the same task and the specific material. With coated abrasives, grain and coating density affect removal; backing flexibility and strength must suit the contour and load. For a hook-and-loop disc, also check diameter, hole pattern and mounting. Krückemeyer GmbH converts suitable coated abrasives into forms such as belts or discs; feasibility depends on the base material, geometry and application.

For belts, explore abrasive belts. If the material, machine or target surface is still unclear, describe your application to us.

05

Questions on Klingspor selection

How do I choose between a Klingspor abrasive belt and a hook-and-loop disc?

The machine, workpiece geometry and processing goal determine the choice. A cloth-backed abrasive belt is used in a suitable belt-grinding process; the documented Klingspor CS 411 Y has zirconia alumina grain on a polyester backing. Hook-and-loop discs such as PS 22 K and FP 77 K are used with a matching backing pad and differ, among other things, in backing and grit. Check the dimensions and mounting of the specific product before selecting it. The product form alone does not show whether the required removal rate or finish will be achieved on your workpiece.

What roles do grain, backing and coating density play in Klingspor abrasives?

These features work together to determine how a coated abrasive performs in a particular application. Klingspor describes hardness and toughness as relevant to grain selection; backing strength and flexibility also matter. An open coating leaves more space between grains, allowing sanding dust from materials prone to loading to escape more readily. This does not establish one best combination for every job. Match grain type, grit, backing and coating density to the material, contour, machine and target finish, then check the features of the specific product.

How do Klingspor PS 22 K and FP 77 K differ?

The documented hook-and-loop sets mainly differ in backing and available grits. The PS 22 K set uses E-weight paper and aluminium oxide; the FP 77 K set combines aluminium oxide with a film backing. Product data associate FP 77 K with finishing paint, filler and similar surfaces, while PS 22 K is described for wood and metal. Both have a resin bond and a semi-open coating. Also check diameter and hole pattern against your backing pad. Select by the actual material and processing step rather than the product family name alone.

When is a Klingspor cutting disc suitable instead of a coated abrasive?

A cutting disc is intended to cut through a workpiece, while abrasive belts and coated abrasive discs work on surfaces. The Klingspor range includes the EDGE cutting disc as a separate product form for cutting metal. Material, dimensions, mounting and the specific product's approval for the machine must align before selection. A cutting product does not replace a grinding step for a defined surface, and an abrasive belt cannot serve as a cutting disc. If the task is unclear, describe the workpiece and the required result.

Can Krückemeyer adapt Klingspor abrasives to my equipment?

Suitable coated abrasives can be converted depending on the base material and application. Krückemeyer GmbH makes abrasive belts and processes roll stock; cutting and die-cutting, as well as laser cutting of suitable materials, are within its documented scope. This does not guarantee feasibility for every Klingspor product or size. Bonded cutting discs are not converted like coated abrasives. Provide the product, material, required shape, dimensions, machine and operating conditions. These details allow the appropriate process and delivery form to be assessed for your application.

06

Request advice

Tell us the material, initial condition, machine and desired surface. We will review the suitable Klingspor product form with you and, for appropriate coated abrasives, a possible converted version.

Check Klingspor abrasives for your application

Describe the processing task and the problem with the current approach. Krückemeyer GmbH will help you select a product and assess whether a suitable delivery form is technically feasible.

Jürgen Müller

KLINGSPOR ABRASIVES

Jürgen Müller

Contact for products

Discuss the material, machine and target surface for your Klingspor selection with Jürgen Müller.
